Hitachi’s Grade Guidance, integrated and developed in cooperation with Topcon, helps complete precision excavation more efficiently by monitoring grade in real time. The new option is now available on the ZX210-6, ZX210LC-6, and ZX350LC-6, and will be offered on additional Dash-6 models in the future.

From trenching and shaping ditches and slopes to digging foundations, Grade Guidance helps increase efficiency. The real-time display of distance-to-grade reduces time to final grade, so jobs can be completed quickly. A real-time grade indicator also allows for grade management without leaving the cab and reduces the need for a grade checker or grade stakes.

Grade Guidance is installed and calibrated at the factory. Full integration into the machine’s cab and structures helps shield key components such as wire harnesses and sensors from damage while conveniently placed joysticks enable easy fingertip control.

Customers can choose 2D Grade Guidance or 3D Grade Guidance. The 2D Grade Guidance with an optional laser receiver displays the elevation of the cutting edge in relation to a reference plane while the 3D Grade Guidance with Global Navigation Satellite System (GNSS) displays position and elevation with respect to a global reference. System data from both options can be sent to ZXLink for analysis, so the machine’s health can be monitored to keep projects running.

In addition to the new factory-integrated Grade Guidance, Hitachi offers an open architecture option that includes sensor mounting brackets to enable installation of a Trimble, Topcon, or Leica aftermarket kit.
